Automatic Labeling Machine

Automatic Adhesive Sticker Round Bottle Labeling Machine

Warranty :2 years
Labeling Speed:20-200pcs/min
Accuracy of Labeling:±1mm
Material: Stainless Steel
Product description: automatic labeling machine,labeling machine,bottle labeling machine,round bottle labeling machine,sticker labeling machine,opp labeling machine,auto labeling machine,Self Adhesive Labeling machine,Adh
INQUIRY

The machine can simultaneously achieve two-sided circumferential surface labeling and labeling features to satisfy the flat bottles, square bottles and bottle shaped single-sided and double side labeling, the entire circumference of the cylindrical body, a half weeks labeling, widely used cosmetics industry, daily chemical industry. Optional Tape printer and inkjet printer to achieve the production date printed on the label and batch information to achieve labeling – endowed integration.

Features

1. All labeling machines are made of SUS304 stainless steel

2. Labeling machine can be equipped bottle feeding table

3. Labeling machine avoid many problems of labor labeling, skew labeling, bubble, wrinkle, irregular labeling etc

4. Labeling machine equips electric-eye to improve the precision for cutting off the label materials.

5. Labeling machine adopts equivalent PLC, positioning module, stepping motor and sensor electrical control system control.

Application

1. For label: self-adhesive labels, self-adhesive film, electronic supervision code, bar code, etc.

2. Applicable products: Requires the side plane, side sweeping surface, the circumferential surface attached label. 3. Industry: Widely used in cosmetics, daily chemical, electronics, pharmaceutical, metal, plastics and other industries.

4. Application examples: Head & Shoulders shampoo flat bottle labeling, Shell Lubricants flat bottle labeling, labeling and fresh wine.

Technical Parameters

Name	Economy Round Bottle Labeling Machine
Labeling Speed	20-200pcs/min(Depending on label length and bottle thickness)
Height of Object	30-280mm
Thickness of Object	30-120mm
Height of Label	15-140mm
Length of Label	25-300mm
Label Roller Inside Diameter	76mm
Label Roller Outside Diameter	380mm
Accuracy of Labeling	±1mm
Power Supply	220V 50/60HZ 1.5KW
Gas Consumption of Printer	5Kg/cm^2
Size of Labeling Machine	2200(L)×1100(W)×1300(H)mm
Weight of Labeling Machine	150Kg
