Empty Bottle Leak Testing Machine

plastic bottle can leakage testing machine

Warranty :2 years
Control:PLC+Touch screen
Capacity:800-1500PCS/H
Automatic Grade:Automatic
Product description: leakage testing machine,plastic bottle leakage testing machine,bottle leakage testing machine,can leakage testing machine,leak detection,leak tester machine,leak tester packaging,leakage test machine,
INQUIRY

LONGSN automation specializes in the production of high-performance,high-precision air tightness testing equipment for plastic products.It uses famous brand PLC and high-precision pressure sensors.Regardless of you are measuring in a big way slightly to 1ml to 300 liter each kind of mid heaven plastic container.No matter that is the soft bag,the grotesque hetero amorphous bottle or the tube,we can provide the ideal leak testing equipment for you.

Plastic bottle can leakage testing machine is designed for leak detection in plastic bottles or containers. Special for use in plastic bottle manufacturers,alcohol-free beverage bottles, machine oil bottles, lubricating oil bottles, cleaning bottles, chemical industrial products bottles, but must be empty detection.

Main Features:

1.High performance,high stability,use foreign high-precision sensors,can detect extremely small leaks;

2.easy operation:one-button automatic leak testing,human-machine interface display leak detection information,use PLC to set different detection parameters according to different products,unqualified products are automatically eliminated

3. Constructs firmly: The steel plate works fuselage, the fluctuation place unifies the guide pillar and the lead screw.

4. The leak testing precision is high, the speed is quick: using the high accuracy digital pressure sensing index error is to press the leak testing, the laser probe head.

5. The price advantage: our leak testing machine is considered today on the field of plastic container for leak testing machine most to have the performance-to-price ratio, obtained the test and confirmation from the global customers in the past several years.

Technical Parameters:

Model	LSN-LT1	LSN-LT2	LSN-LT4	LSN-LT8
Location number	1	2	4	8
Speed	600-1000pcs/h	800-1500pcs/h	2000-3000pcs/h	2500-4000pcs/h
Range	1ml-50L	1ml-30L	1ml-30L	10ml-2L
Size	16006201600MM	16006201600MM	20007501800MM	20007501800MM
Height	800-1100MM	800-1100MM	800-1100MM	800-1100MM
Conveyor length	1600MM	1600MM	2000MM	2000MM220V 50HZ
Power	220V 50HZ	220V 50HZ	220V 50HZ	220V 50HZ
