Empty Bottle Bagging Machine

Auto PET HDPE PP PE plastic jerrycan barrel empty bottle bag packing bagging machinery

Warranty :2 years
Control:PLC+Touch screen
Capacity:3000-8000pcs/h
Automatic Grade:Automatic
Product description: packing empty bottle machinery,packing empty bottle machinery,packing empty bottle machinery,packing empty bottle machinery,pe bottle bag packing machinery,plastic bottle packing machine,pet bottle ba
INQUIRY

Auto packing empty bottle jerrycan cans machine/plastic pet bottle packing machinery replaces the traditional manual packing,improve the production efficiency and reduce the labor costs,achieve the complete product post-processing automatic production line,effectively avoid the product contamination produced by hand touching,widely used in cosmetic,food,beverage,medicine and other fields.

Features:
High speed,high production capacity
Big adjustable range,suitable for many products

Wide application scope,can be connected with other machines,also can be used as a single machine

Item	Specifications	Remarks
Container requirements	200ml-5L, Ranging from 200 ml to 5L; the ratio between height and diameter should be less than 4
Packing sizes	(400-1200)(400-650)(50-300)(LWH) Length: 400 to 1200 mm; Width: 400 to 650 mm	Can be customized
Conveyor length	Standard conveyor: LW 2200mm114.3mm	Can be customized.
Conveyor height	850±50 mm	Can be customized.
Air pressure	6-8 Bar	Supplied by the purchaser
Power consumption	2KW
Output	3,000 to 4,000 per hour for 500 ml bottle
Main Specifications	PLC-- MITSUBISHI /Japan Touch screen –SIEMENS- Germany Laser probe--Autonics/ Korean Air valves-- FESTO / Germany penumatic and cylinder --FESTO / Germany
