Automatic 3 gallon 5 gallon 20 liters water bottle making machinery plastic extrusion blow molding machines
|
Parameters
|
Units
|
LSN90S
|
LSN100D
|
|
Material
|
|
PE,PP,PV,PVC,PA
|
PE,PP,PV,PVC,PA
|
|
Number of die head
|
set
|
1,2,3,4
|
1,2,3,4
|
|
Max Container capacity
|
|
30L
|
30L
|
|
Screw diameter
|
mm
|
90
|
100
|
|
Screw L/D ratio
|
-
|
28
|
28
|
|
(50HZ)Screw rpm(50hz)
|
r/min
|
10-70
|
10-60
|
|
(PE)Extrusion capacity per hour
|
kg/h
|
160
|
200
|
|
Number of heaters
|
-
|
4
|
5
|
|
Opening stoke
|
mm
|
900
|
900
|
|
Platen size
|
mm
|
500*540
|
500*540
|
|
Clamping force
|
KN
|
170
|
170
|
|
Dry cycle time
|
s
|
6
|
9
|
|
Air pressure
|
Mpa
|
0.8
|
0.8
|
|
Compressed air comsumption
|
m3/min
|
4
|
6
|
|
Machine dimension(L*W*H)
|
mm
|
5000*2900*3950
|
5200*4700*4000
|
|
Machine net weight
|
T
|
9.5
|
16
|
|
Extruder heating power
|
kw
|
22
|
27
|
|
Hydraulic motor
|
kw
|
18.5
|
18.5
|
|
Total power
|
kw
|
106
|
121
|
