空瓶测漏机

plastic bottle leak test machine

Warranty :2 years
Control:PLC+Touch screen
Leak volume:200ml-10L
Material: Stainless Steel
产品描述：plastic bottle leak test machine,leak test machine,bottle leak test machine,leak detection, leak detector,30l jerrycan leak test,engine oil bottle leak test,bottle leak tester,leak tester machine
在线订购

Products Character

1.Operates easily: one-botton leaking tests automatically, the text demonstrats leak testing information, the defective products reject the production line automatically.

2. Constructs firmly: The steel plate works fuselage, the fluctuation place unifies the guide pillar and the lead screw.

3. The leak testing precision is high, the speed is quick: using the high accuracy digital pressure sensing index error is to press the leak testing, the laser probe head.

4. The price advantage: our leak testing machine is considered today on the field of plastic container for leak testing amchine most to have the performance-to-price ratio, obtained the test and confirmation from the global customers in the past several years.

Technical Parameters
Model	LSN-LT1	LSN-LT2	LSN-LT4	LSN-LT8	LSN-LN3/10	LSN-LTS1
Capacity	600-1000PCS/H	800-1500PCS/H	2000-3000PCS/H	3000-5000PCS	6000-10000PCS/H	400-500PCS/H
Bottle Range	1ml-50L	1ml-30L	1ml-30L	1ml-30L	1ml-10L	90L-200L
Overall Size	16006201600mm	16006201600mm	16006201600mm	By Order	By Order	160013501600
Height range	800-1100mm	800-1100mm	800-1100mm	By Order	By Order	800-1100mm
Conveyor Length	1600mm	1600mm	1600mm	By Order	By Order	By Order
Power	220V 50HZ	220V 50HZ	220V 50HZ	220V 50HZ	220V 50HZ	220V 50HZ
