Drink water bottle plastic injection molding machine preform making machine
|
ITEM
|
UNIT
|
DATA
|
|||
|
Injection Unit
|
Screw Diameter
|
mm
|
65
|
70
|
75
|
|
Screw L/D Ratio
|
L/D
|
22.6
|
21
|
19.6
|
|
|
Injection Volume
|
cm3
|
996
|
1155
|
1325
|
|
|
Shot Weight
|
g
|
906
|
1051
|
1206
|
|
|
Injection Pressure
|
Mpa
|
203
|
175
|
152
|
|
|
Clamping Unit
|
Clamping Force
|
kN
|
3300
|
||
|
Opening Stroke
|
mm
|
660
|
|||
|
Mould Thickness(Min-Max)
|
mm
|
250-680
|
|||
|
Space Between Tie-Bars
|
mm
|
680×680
|
|||
|
Ejector Force
|
kN
|
91
|
|||
|
Ejector Stroke
|
mm
|
170
|
|||
|
General
|
Motor Power
|
kW
|
30
|
||
|
Heater
|
kW
|
23.3
|
|||
|
Pump Pressure
|
Mpa
|
16
|
|||
|
Machine Dimension
|
m
|
7.4×1.8×2.5
|
|||
|
Machine Weight
|
T
|
13
|
|||
|
Mould Orientation Ring Diameter
|
mm
|
Φ160
|
|||
|
Nozzle Radius
|
mm
|
SR15
|
|||
