组盖垫片机

Automatic plastic cap liner inserting machine

Warranty :2 years
Control:PLC+Touch screen
Capacity:100-200 Pcs/MIN
cap diameter:10-50mm
产品描述：Automatic plastic cap liner inserting machine,cap lining machine, cap wadding machine,cap liner inserting machine, wad insert machine, cap lining machinery,cap wadding machinery,wad inserting machiner
在线订购

Automatic plastic cap liner inserting machine is putting the liner or gasket into the cap.Automatic cap lining machine , which can cut the foil roll into liner and insert the liner into cap at the same time, with the speed up to 120 pieces/min, avoiding the manual pollution and improving the product efficiency as well.

It has ability to run different size cap. The machine’s operation is fully automatic, highlighted by Detal programmable logic controller(PLC), a touch screen operator interface terminal, missing foil cap director and alarm system.

this cap lining machine is helpful to the cap production, it will enduremany years of consitent production.

model	LSN-L2
Speed	Max 120 caps/min
Electricity power	380V, 50HZ
power	2000W
Air compression	30L/min, ≥0.4Mp
host equipment size	1100mm900mm1400mm
Cap elevator and cap feeding device	1700mm750mm1200mm
Foil sending device	500mm500mm750mm
Waster soil sending device	500mm500mm650mm
conveyor	1200mm100mm200mm
Machine weight	1100Kg
